ELECTRICAL KIT
AM80 Agile Agile GEN2
COLORS
Ultralight
SIZES
45
MECHANICAL SPECIFICATIONS
Alu frame. Hydroformed 700c, integrated battery, internal cables
Fork HL CH-187 HLO 700c, aluminum with aluminum crown, 65mm travel, 30mm stanchions
FSA headset integrated forward 1"1/8
Alu 170mm crankset, FSA 38T
Shimano Acera RD-M3020 / L-TWOO RD-V4009-L-2, 9 speed derailleur
Shimano SL-M315 PushPull, 8s / L-TWOO SL-V4009-9W-2, 9s shifters
Hydraulic disc brakes Shimano BR-MT200, 180 mm CL rotor
Shimano HG200 8s 12-32 / L-TWOO CS-A5 9s 11-34 sprocket set
Alu Comfort pedals
Shimano TX505 32h, CL, quick release hubs
Radiale E25 700c rims, double wall, 32h, disc
Au over, ahead, adjustable handlebar stem
Alu handlebar over TKK, 640mm, rise 25mm
Suspended Seatpost 40mm, 30.9mm
Selle Royal Lancia saddle
Schwalbe Road Cruiser tires 700x47c, with reflective line, puncture proof
Mudguards Fast single stay, edge
L type chain cover, edge
14mm aluminum rear rack with spring, load 25kg
Front (30 lux) and rear Axa LED external lights, controlled by display and twilight sensor
Size 45
Ultralight color
Note Ursus adjustable rear stand, bell, key ring
ELECTRICAL SPECIFICATIONS
Maximum torque 100 Nm
Torque sensor type
522 battery
2A Europlug battery charger type
Charging time 100%: 7h:45m / 80%: 5h48m
Max assisted speed 25 km/h
Atala A10 LCD CAN display, glass/metal with remote control
Power 5 levels, Power adjustment level1: 50% level2: 100% level3: 150% level4: 200% level5: 250%
Other functions Walking assistance External light control Speed ​​information Battery information
