Technical Specifications

• Motor Unit

  1. Motor

     Bosch Performance Line CX BDU3840 - Kiox 300

  2. Battery

     Bosch Powertube 800 Wh

• Frame

  1. Frame Kit

     Bianchi e-Vertic FX, aluminum, 12x148 mm rear thru-axle, Post mount 180 rear caliper, 150 mm front travel, 140 mm rear travel, Internal cable routing in headset, 800 Wh battery compatible, sizes 40-44-48-53

  2. Fork

     RockShox Lyrik 29", 150 mm travel, 1.5" tapered steerer tube, 35 mm stanchions, Maxle Stealth 15x110 Boost front axle, Rotor: minimum 180 mm, maximum 220 mm, Rake 44 mm

  3. Rear Shock

     RockShox Deluxe Select, 210/52.5 mm for size SM, 210/55 mm for sizes MD, LG, XL, Debonair Progressive, Damper Setting R, Rebound Setting R55, Compression Setting C34, External Rebound Adjustment

  4. Headset

     FSA 1.5" for tapered steerer tube, Internal "dual side" cables, HBS rotation lock system

• Drivetrain

  1. Shifters

     Sram SX Eagle, single click

  2. Rear Derailleur

     Sram SX Eagle, 12 speed

  3. Crankset

     FSA CK-745/IS, forged aluminum - 165 mm crank arm length: 165 mm

  4. Chain

     Sram SX Eagle, 12 speed

  5. Cassette

     Sram PG-1210 Eagle, for HG freehub, 11-13-15- 17-19-22-25-28-32-36-42-50T

• Brakes

  1. Brakes

     Sram DB4, 4-piston calipers, mineral oil

  2. Brake Levers

     Sram DB4, included with brake

  3. Rotors

     FRONT: Sram Centerline, 200 mm / REAR: Sram Centerline, 200 mm

• Wheels

  1. Wheels

     Velomann Rim: V22M, 622x28, 32 holes, Tubeless Ready; Hubs: Shimano TC500 thru-axle

  2. Tires

     Pirelli Scorpion 29x2.6 E-MTB, 60TPI

• Handlebar

  1. Stem

     Velomann 1" 1/8, Barbore diameter: 35 mm Sizes: 50 mm

  2. Handlebar

     Velomann Aluminum, Rise: 18 mm, Barbore diameter: 35 mm, Sizes: 780 mm

  3. Tape / Grips / Extensions

     Herrmans Luna lock 130 mm

• Saddle

  1. Seatpost Clamp

     Bianchi Custom

  2. Seatpost

     Velomann Diameter 31.6 mm, Internal cable routing length: 100 mm - SM, 125 mm - MD, 150 mm - LG/XL

  3. Saddle

     Velomann Velomann Gnd Full-fit Start Up, Carbon-steel rails, 262 mm x 145 mm

• Bianchi reserves the right to make changes, based on component availability, without prior notice.
