Mechanical specifications
Frame
Full carbon 29", Toray T700, integrated battery, internal cable routing, 150 mm rear travel, E-Thru 12x148 mm thru axle
Fork
Rock Shox Recon Silver RL, 150 mm, Maxle Lite 15x110 mm, Solo Air, 1.5" tapered steerer, fork lockout
Rear shock
Rock Shox Deluxe Select R 230x65, Debon Air
Rear derailleur
Shimano XT RD-M8100 SGS, Shadow Plus
Brakes
Shimano BR-MT420, four pistons, SM-RT30 203 mm / 203 mm rotors
Full Specifications
| Component | Specification |
|---|---|
| Frame | Full carbon 29", Toray T700, integrated battery, internal cable routing, 150 mm rear travel, E-Thru 12x148 mm thru axle |
| Fork | Rock Shox Recon Silver RL, 150 mm, Maxle Lite 15x110 mm, Solo Air, 1.5" tapered steerer, fork lockout |
| Rear shock | Rock Shox Deluxe Select R 230x65, Debon Air |
| Headset | FSA No.57E tapered 1"1/2 |
| Crankset | FSA 34T |
| Rear derailleur | Shimano XT RD-M8100 SGS, Shadow Plus |
| Shifters | Shimano Deore SL-M6100 Rapidfire-Plus, 12 speed, I-spec |
| Brakes | Shimano BR-MT420, four pistons, SM-RT30 203 mm / 203 mm rotors |
| Cassette | Shimano CS-M6100 12 speed 10/51 |
| Pedals | Alu MTB Full+ |
| Front hub | Shimano TC500B, 15x110, Center Lock, 32 holes |
| Rear hub | Shimano TC500B, 12x148, Center Lock, MicroSpline, 32 holes // Formula, 12x148, CL, MicroSpline, 32 holes |
| Rims | RADIALE X30, eDesign | asymmetric, Tubeless Ready, 622x30c |
| Stem | Aluminum, 31.8 mm diameter |
| Handlebar | Aluminum, 780 mm, 31.8 diameter, 15 mm rise |
| Seatpost | Dropper Alpha 1, 31.6 mm, remote control |
| Saddle | Whistle Performance |
| Tires | Schwalbe Tough Tom 29”x2.25” / Vittoria Barzo |
| Sizes | 40 / 44 / 48 / 52 |
| Wheel diameter | 29 inches |
