Technical specifications
-
Frame
-
Frame Set
Bianchi Infinito Pro, Flat mount 140/160, PressFit 86.5x41 mm, Thru Axle 12x142 mm, Sram UDH compatible, Max chainring compatibility: 46-54T, Internal cables, Max tire clearance: ETRTO 622-40 sizes 53-55-57 -
Fork
Bianchi Infinito, Flat mount caliper 140/160, Thru-axle, OLD: 100 mm, Steerer tube diameter: 1"1/8 -
Headset
Acros for integrated cables
-
-
Drivetrain
-
Shifters
Shimano Ultegra Di2, ST-R8170 lever-shifter, BR-R8170 caliper -
Rear Derailleur
Shimano Ultegra Di2, RD-R8150, 12sp -
Front Derailleur
Shimano Ultegra Di2, FD-R8150 -
Crankset
Shimano Ultegra, FC-R8100, 4iiii precision 3+ dual side power meter, 50x34T Crank length: 170 mm (53-55 cm); 172.5 mm (57 cm) -
Bottom Bracket
Shimano SM-BB71-41B, press fit for road -
Chain
Shimano CN-M7100 -
Cassette
Shimano Ultegra, CS-R8101 11-34T, 11-12-13-14-15-17-19-21-24-27-30-34T
-
-
Brakes
-
Brakes
Shimano BR-R8170 Hydraulic disc brake -
Brake Levers
Included with shifter -
Rotors
FRONT: Shimano RT-CL800 Center Lock with Ice Tech, 160 mm / REAR: Shimano RT-CL800 Center Lock with Ice Tech, 160 mm
-
-
Wheels
-
Wheels
Bianchi Reparto Corse RC 49R, Carbon rim, 49 mm profile, 700x25c, 24h, Tubeless ready, Straight pull spokes, Ratchet system, HG11 freehub -
Tires
Pirelli P Zero Race TLR, 35-622, 120 TPI
-
-
Handlebar
-
Stem
Bianchi Reparto Corse integrated handlebar, carbon, for Acros integrated cable headset, 125 mm drop, 80 mm reach Sizes: 100/400 mm (53-55 cm); 110/400 mm (57 cm) -
Handlebar
Included with stem -
Tape / Grips / Extensions
Bianchi Hexagon tape, 2.5 mm thickness, black
-
-
Saddle
-
Seatpost Clamp
Bianchi Custom -
Seatpost
Bianchi Infinito, Countervail technology, carbon, aero-flex section length: 350 mm, 0 offset (53 cm); 350 mm, 20 offset (55-57) -
Saddle
Prologo Dimension R2 CPC, Carbon Rails, Length: 245 mm, Width: 143 mm, Weight: 145 g
-
-
Bianchi reserves the right to make changes, based on component availability, without prior notice.
